Collins 32v Transmitter 32 V TX

Power Source
115 volts AC 50/60 cps single phase.

PA Plate Power Input
The nominal rated power input of the Collins 32v-2 is 120 watts on phone and 150 watts on CW.

Complete coverage of the 80, 40, 20, 15, 11 and 10 meter bands is obtained with this unit. Quick band-change is accomplished by band switching on all stages.

The permeability tuned circuits of the 1st, 2nd and 3rd multipliers have their
tuning controls ganged with the oscillator.


The final tank consists of impedance matching network with two separate controls located on the front panel, one for tuning and one for loading.

Two heavy duty toggle switches control the low voltage and high voltage circuits.
The switches are arranged so that the high voltage cannot be applied until the low voltage circuits have been energized.

A push-to-talk switch associated with the microphone, may be used to apply the high voltage instead of the HV toggle switch for added convenience.

A CW side tone oscillator is incorporated in this unit with which CW transmissions can be monitored.

Manuals and Circuits
available Details Below
On Paper CD or Download

Click Here


The Collins 32V Transmitter manual contains 63 A4 pages paper copy including Circuits Component lists and Layouts.
Manuals are Available Worldwide as a Download on CD or Paper Copy.

Manual 63 A4 pages worldwide

Printed Paper Copy or on CD are Plus Postage.

( For all Payment Options plus UK and Overseas Postage )
( Please Click the Payment Links Below )

We do all we can to provide the very best that is available for you.
But in the unlikely event that any data should not be as you expected.
A refund is always available. Kind Regards Allen and Alanna.


Manuals are Available Worldwide as Paper Copy on CD or as a Download

Thank you for your interest. Allen and Alanna G0RIT
