Reception Set R 109 R109A R109B R109C
Wireless Set R109 Communications Receiver

The R109A was designed as a general purpose "Army Reception Set" for use with a vehicle-station or at a fixed location.

Frequency Coverage
2.0 to12.0 Mc/s in 2 bands.

Band 1 : - 2.0 to 4.9 Mc/s.

Band 2 : - 4.0 to 12.0 Mc/s.

Both these bands are directly calibrated on a very good slow-motion dial.

An internal speaker is fitted and can be switched out when headphones are being used.

The receiver has a BFO for CW reception and also a crash-noise limiter of the simple type.

A panel socket for a plug-in lamp is provided for use when working in the dark.


Power Supply
The power supplies are incorporated in the receiver which is designed to run from a 6 volt accumulator, it therefore has a vibrator HT pack giving a well smoothed  and filtered 150 volt HT.

With a 6 volt battery supply the load is 2 amps.

Valves
The receiver uses three different valve types as follows : -
RF ARP38
Mixer ARP12 ( VP23 )
Oscillator ARP12
1st and 2nd IF amp ARP12
Detector and Audio AR8 ( HL23DD )
Output amp AR8

Except for the ARP38 all valves are directly heated.

The R109A receiver came complete with a spare set of valves and a spare vibrator  located inside the set.
