Solar CB 1-60 CB1 60 Analyzer Resistance Capacitance Bridge

Condensers may be tested for capacity, leakage, open circuit, shorts, intermittent operation and power factor.

More than forty five linear inches of accurately calibrated markings, on five colour coded scales, are provided for convenient measurement of capacity and resistance.

These tests are made on a Wien bridge with five direct reading ranges.

The power factor of all types of electrolytic condensers can be read directly from a scale which is calibrated zero to 50% power factor.

The capacity range of this instrument is from .00001 mfd. to 70 mfd. and the resistance range is from 50 ohms to 2,000,000 ohms.

The use of a bridge circuit has been made possible by the unusual detector arrangement employed. This detector arrangement consists of a highly sensitive 6E5 cathode ray tube connected across the output of the bridge.

The leakage test part of the equipment consists of a D.C. power supply and a Neon lamp.

A switch is provided with voltage settings covering practically all electrolytic and paper condensers which may be encountered in the field.

Solar CB 1-60.jpg (19229 bytes)


The Manual Contains the Following :-

Operating Instructions and Circuit Diagram total 20 Pages.



Manual Circuit and
Operation Instructions
Details Below
On Paper CD or Download

Click Here


Solar CB 1-60 CB1 60 Analyzer Resistance Capacitance Bridge
Manuals are Available Worldwide as a Download on CD or Paper Copy.

Manual containing  20 pages including the Circuit with Component values.

Manual
20 A4 pages worldwide

Printed Paper Copy or on CD are Plus Postage.

( For all Payment Options plus UK and Overseas Postage )
( Please Click the Payment Links Below )

We do all we can to provide the very best that is available for you.
But in the unlikely event that any data should not be as you expected.
A refund is always available. Kind Regards Allen and Alanna.
