The TGY 2 a marine transmitter the control unit 886 is pictured below unfortunately I do not have the interconnecting cables or power supply.

The modulator is part of the unit shown amplitude modulation and CW would have been the modes of operation.

The unit is in good condition and when the other bits are found will be put on air, amateur bands of course.

Control unit 886 scruffy condition but nothing a spray and re-lettering can not fix.

TGY 2 Control.jpg (30188 bytes)
